STMicroelectronics STM32L052T8Y7 WLCSP(36) Device

Adapters for Automated Programmers

8th Gen	9th Gen
FVE4ASML36BGC, FVE4ASML36BGJ (obs.), FVE4ASML36BGC, FVE4ASML36BGJ (obs.)	FVE4ASML36BGC, FVE4ASML36BGJ (obs.)

Adapters for Manual Programmers

8th Gen	9th Gen
FVE4ASML36BGC, FVE4ASML36BGJ (obs.), FVE4ASML36BGC, FVE4ASML36BGJ (obs.)	FVE4ASML36BGC, FVE4ASML36BGJ (obs.)

Adapters for Engineering Programmers

Last Updated: 05/18/2023

If the device is not yet supported by your BPM programmer (Generation), request Device Support

Request Support Options

Note

IMPORTANT: ARM-based 32-bit MCU with Flash 64KByte Flash Memory is mapped to Data Pattern: 8000000h-800FFFFh 2KByte Data Memory in EEPROM is mapped to Data Pattern: 8080000h-80807FFh Default device range is set to 8000000h-80807FFh. Selecting Erase operation will do global erase including the IAP area and option bytes. 12 Option Bytes are mapped to Data Pattern: 1FF80000h-1FF8000Bh These option bytes are not verified after program with this algorithm if Boot1 bit is set to zero or if device is set to read protection level 1 or level 2.

Data Pattern Address	Bits
1FF80000h	FLASH_OPTR[15:0]
1FF80002h	nFLASH_OPTR[15:0]
1FF80004h	FLASH_OPTR[32:16]
1FF80006h	FLASH_OPTR[32:16]
1FF80008h	FLASH_WRPROT[15:0]
1FF8000Ah	nFLASH_WRPROT[15:0]

Selecting Erase operation will do global erase including the IAP area and option bytes. If RDP protection is set to level 1(None AAh Non CCh) the main Flash memory and the backup registers (RTC_BKPxR in the RTC) are totally inaccessible. If RDP protection is set to level 2(CCh) device debug interface is disabled. Any operation on device fails. If BOOT1 option bit is set to ‘0’ device will not be accessible by this algorithm. Stand alone operation might fail if device was programmed with executable code. ‘



BPM does not sell programmable devices, nor do we program devices directly. BPM makes programmers and accessories to make programming in-house fast, easy, and profitable.

More Info

Additional information

8-bit Bytes	536346636
Manufacturer	STMicroelectronics
Packages	WLCSP(36)
Part Number	STM32L052T8Y7
Set programming	Yes
Vcc(program)	3.3
Package
